Plan d'adressage IMDEO
Matrice d'adressage
| N° VLAN |
Nom VLAN |
Nombre d’hôte |
Masque |
RĂ©seaux |
Passerelles |
Diffusion |
| 3 |
COM |
21 |
255.255.255.224 (/27) |
192.168.1.0 |
192.168.1.30 |
192.168.1.31 |
| 2 |
RH |
16 |
255.255.255.224 (/27) |
192.168.1.32 |
192.168.1.62 |
192.168.1.63 |
| 9 |
ADM |
11 |
255.255.255.240 (/28) |
192.168.1.64 |
192.168.1.78 |
192.168.1.79 |
| 4 |
DIR |
6 |
255.255.255.248 (/29) |
192.168.1.80 |
192.168.1.86 |
192.168.1.87 |
| 5 |
COMPTA |
4 |
255.255.255.248 (/29) |
192.168.1.88 |
192.168.1.94 |
192.168.1.95 |
| 6 |
REUNION |
30 |
255.255.255.224 (/27) |
192.168.2.0 |
192.168.2.30 |
192.168.1.31 |
| 10 |
FAI |
2 |
255.255.255.252 (/30) |
192.168.1.96 |
192.168.1.98 |
192.168.1.99 |
| 51 |
SERVEURS |
3 |
255.255.255.0 |
172.16.51.0 |
172.16.51.252 |
172.16.51.255 |
Plage d'adressage
| Nom du service |
DĂ©but |
Fin |
| COM |
192.168.1.1/27 |
192.168.1.30/27 |
| RH |
192.168.1.33/27 |
192.168.1.62/27 |
| ADM |
192.168.1.65/28 |
192.168.1.78/28 |
| DIR |
192.168.1.81/29 |
192.168.1.86/29 |
| COMPTA |
192.168.1.89/29 |
192.168.1.94/29 |
| REUNION |
192.168.2.1/27 |
192.168.2.30/27 |
| FAI |
192.168.1.97/30 |
192.168.1.98/30 |
| SERVEURS |
172.16.51.1/24 |
172.16.51.254/24 |
